** 1 fppa units, 12-bit, 14 io, 1.5kw otp, fppa^tm controller **

(1) one processing unit operating mode
(2) 1.5kw otp program memory
(3) 88 bytes data ram
(4) 86 powerful instructions
(5) programmable stack pointer to provide adjustable stack level
(6) all data memories are available for use as an index pointer
(7) band-gap circuit to provide 1.20v reference voltage
(8) one hardware 16-bit timer
(9) two hardware 8-bit timers with pwm generation
(10) up to 12-channel 12-bit resolution adc
(11) provide adc reference high voltage: external input, internal vdd, band-gap 1.20v, 4v, 3v, 2v
(12) provide 1t 8x8 hardware multiplier
(13) support fast wake-up
(14) eight levels of lvr reset ~ 4.1v, 3.6v, 3.1v, 2.8v, 2.5v, 2.2v, 2.0v, 1.8v
(15) 14 io pins
(16) four selectable external interrupt pins
(17) every io pin can be configured to enable wake-up function
(18) operating voltage range: 2.2v ~ 5.5v
(19) operating frequencyvoltage for both crystal modeihrc mode
(20) dc ~ 8mhz@vdd≧3.1v dc ~ 4mhz@vdd≧2.5v dc ~ 2mhz@vdd≧2.2v
(21) pmc131 is high eft series with -40°c ~ 85°c operating temperature range
(22) pms131pms130 are general purpose series with 0°c ~ 70°c operating temperature range
